Diffussed Silicon Pressure Transmitter WPCK05
Summary:
WPCK05 series diffused silicon pressure transmitter is integrated with high-precision diffused silicon pressure core, the internal special integrated circuit converts the sensor millivolt signal into a standard current signal, which can be directly connected with the computer interface card, control instrument, intelligent instrument or PLC, and the current output mode can be used for remote transmission. WPCK07 is a small size, light weight, all stainless steel sealed structure transmitter, which can be used in corrosive environment. The product has extremely high vibration and impact resistance and easily to install. I’s widely used in process control, automobile, medical equipment, HVAC and other fields
Application:
Process control system
Pressure calibration instrument
Biomedical instruments
Refrigeration equipment and HAVC system
Ships and navigation
Pipeline pressure monitoring
Feature:
* Stainless steel structure, multi thread structure
* Wide temperature compensation-10~+70℃
* Multi output methods
* Excellent anti-interference ability
* High reliability
* Hi Accuracy
* Low consumption
Share To:
APPLICATION
The combustion gas used in the city is supplied to urban residents from the gas source point through the gas distribution and supply system. The main component of the gas distribution system is the gas pipeline. Compared with other pipelines, the tightness of gas pipelines has particularly strict requirements,
Didn't Find Your Tarket Application?
Winsen offers tailor-made gas sensor solutions for your industry
PARAMETER
Technical Data Sheet
|
Basic Parameter Index |
||
|
Pressure range |
-100kPa～0～10kPa…100MPa |
|
|
Pressure Reference |
GaugePressure/AbsolutePressure/Sealed Gauge Pressure |
|
|
Power supply |
12-30V |
|
|
Output |
0.5-4.5V,0-5V,1-5V,0-10V,1-10V |
|
|
Accuracy |
±0.5%FS |
|
|
Hysteresis |
0.1%FS |
|
|
Repeatability |
0.1%FS |
|
|
Low Consumption |
Standby current＜100nA |
|
|
Temperature Drift |
35kPa：±2%FS(0℃～60℃） Others：±1.5%FS(-20℃～85) |
|
|
Response Time |
≤1ms |
Up to90%FS |
|
Overload pressure |
Refer to the pressure range chart |
|
|
Working life |
≥1×10⁶ Pressure cycle |
|
|
Environment Temperature |
≥1×10⁶ Pressure cycle |
|
|
EnvironmentTemperature |
-30℃～105℃ |
|
|
Storage Temperature |
-40℃～125℃ |
|
|
EMC |
Immunity:IEC 61000-6-2 Radiation:IEC 61000-6-3 |
|
|
Vibration Resistance |
Impact：200g/1ms；IEC 60068-2-27 Free fall：1m；IEC 60068-2-32 |
|
|
Protection level |
IP65 |
|
|
Static electricity |
IEC 61000-4-5 Level3 |
|
|
Voltage Withstand |
Current Output：500V/AC 1min Voltage Output：250V/AC 1min |
|
|
Media Compatible |
Media compatible with SS 316L |
|
|
Size of Hexagon |
SW27 |
|
|
Ex-proof level |
ExiaⅡCT6 |
|
|
Thread |
M20*1.5（Default） |
Optional |
|
Lead-out Method |
Cable/Cable+TerminalPH2.0-5P |
Optional |
