Electrochemical Carbon Monoxide CO Sensor MEs-CO


+
  • MEs-CO.png

Summary:

MEs-CO Carbon monoxide sensor is a fuel cell type sensor. Carbon monoxide and oxygen undergo corresponding REDOX reaction on the working electrode and the opposite electrode and release charge to form current. The current generated is proportional to the concentration of carbon monoxide and follows Faraday's law.

Widely suitable for carbon monoxide concentration detection in smart homes, commercial buildings, underground garages, fire monitoring and other fields.

Feature:

* Low consumption
* High precision
* High sensitivity
* Wide linear range
* Good anti-interference ability
* Long lifespan
* Excellent repeatability and stability

Share To:


APPLICATION

CO Alarm

In daily life, coal, charcoal, and liquefied petroleum gas will produce carbon dioxide after combustion, and carbon dioxide will be reduced to CO in a poorly ventilated environment. CO is a suffocating poison gas, which is colorless, odorless, and non-irritating. If CO leaks, it cannot be discerned by the eye or nose. As we all know, poor ventilation during combustion can lead to a decrease in oxygen content, resulting in incomplete combustion and increased CO production. When the concentration of CO in the room continues to increase, people will gradually feel headache, nausea, difficulty breathing, collapse, dizziness.

MORE +

Didn't Find Your Tarket Application?
Winsen offers tailor-made gas sensor solutions for your industry

Contact us

PARAMETER

Specification Product Size

Technical Data Sheet

Detection gas

CO

Measurement Range

0~1000ppm

Max detecting concentration

2000ppm

Sensitivity

(1.0~2.0) nA/ppm

Resolution

1ppm

Response time(T90)

<30S

Load resistance(recommended)

500/1k/2k Ω

Repeatability

<3﹪output value

Output Linearity

linear

Zero drift(-20℃~40℃)

≤10ppm

Temperature range

-20℃~80℃

Humidity range

15﹪~90﹪RH

Pressure range

standard atmosphere±10%

Lifespan

10 years
