Electrochemical Carbon Monoxide Sensor Module ZE730-CO

Summary:

ZE730-CO is a general-purpose, miniaturized gas detection module. The module is equipped with a fuel cell type electrochemical button sensor, which not only has low power consumption, but also can effectively avoid the risk of leakage of traditional electrochemical sensors. In terms of circuit, the instrument amplifier, high-precision AD converter, etc., the detected gas concentration is converted into a digital signal, and the data transmission can be carried out through serial port, PWM and other signals, not only the signal is stable, but also a multiple choice.

Application:
Vehicle lithium battery failure detection, smart home CO gas detection, portable carbon monoxide detector, etc.

Feature:

* High temperature resistance

* Fast response

* Low power consumption

* High precision

* Long life

INQUIRY

MANUAL

Share To:

APPLICATION

Vehicle CO Detection

If you rest in a closed car while parking and idling, shortness of breath may occur over time. If you sleep with the air conditioner turned on in the cab or with a truck heater, it is easy to inhale too much carbon monoxide and cause poisoning and loss of consciousness. In severe cases, life will be lost.

MORE +

CO Alarm

In daily life, coal, charcoal, and liquefied petroleum gas will produce carbon dioxide after combustion, and carbon dioxide will be reduced to CO in a poorly ventilated environment. CO is a suffocating poison gas, which is colorless, odorless, and non-irritating. If CO leaks, it cannot be discerned by the eye or nose. As we all know, poor ventilation during combustion can lead to a decrease in oxygen content, resulting in incomplete combustion and increased CO production. When the concentration of CO in the room continues to increase, people will gradually feel headache, nausea, difficulty breathing, collapse, dizziness.

MORE +

Didn't Find Your Tarket Application?
Winsen offers tailor-made gas sensor solutions for your industry

PARAMETER

Specification Product Size

Technical Data Sheet

Model	ZE730-CO
Detecting gas	Carbon Monoxide
Interfering gas	Hydrogen, ethylene etc
Output	UART/PWM
Working Voltage	5V±0.5VDC
Pre-heating Time	3min
Response Time	＜40s
Recovery Time	1min
Detecting Range	0～1000ppm
Resolution	1ppm
Working Temperature	-20℃～80℃
Working Humidity	15%RH-90%RH（No condensation）
Stock Temperature	-10~55℃
Stock Humidity	30%～60%RH
Life Span	10 years (In air)

Unit：mm
