Electrochemical Formaldehyde Sensor ZE07A-CH2O
Summary:
ZE07A-CH2O electrochemical formaldehyde module is a general-purpose and miniaturized module. Using the electrochemical principle to detect CH2O in the air has good selectivity and stability. Built-in temperature sensor for temperature compensation; at the same time, it has digital output and PWM output, which is convenient to use. ZE07A-CH2O is a general-purpose gas module designed and manufactured by closely combining mature electrochemical detection technology with sophisticated circuit design.
Feature:
* High sensitivity & resolution
* Low power consumption
* UART and PWM signal output
* Good stability and excellent anti-interference ability
Share To:
APPLICATION
Winsen is a world-renowned gas sensor manufacturer and supplier. A variety of sensors are intelligently combined and developed to form the overall concept of the module. The extremely flexible assembly combination can meet the sensitivity, corresponding speed, stability, power consumption and size requirements of all air purifiers on the market.
Winsen Technology has provided accurate gas detection solutions for more than 1,000 fresh air enterprises, which has also established the influence of Winsen sensors in the air purification market. In the future, Winsen will launch more intelligent and miniaturized all-in-one integrated modules to meet the various needs of different customers in the ventilation system market.
Formaldehyde detector is an instrument for detecting formaldehyde. Generally, semiconductor sensors and electrochemical sensors are used to realize the rapid semi-quantification of formaldehyde in indoor air on the spot, which is characterized by simple structure, small size, intuitive,easy to carry and use.
The World Health Organization's "Indoor Air Pollution and Health" pointed out that the current level of indoor air pollution is 5-10 times higher than outdoor pollution, and 4% of global diseases are related to indoor air quality, and about 2 million people die prematurely each year from diseases caused by indoor air pollution.
Didn't Find Your Tarket Application?
Winsen offers tailor-made gas sensor solutions for your industry
PARAMETER
Technical Data Sheet
| Model No. | ZE07A-CH2O |
| Detection Gas | CH2O formaldehyde |
| Interfering gas | Gases such as alcohol, carbon monoxide |
| Output Data | PWM |
| UART output (3.3V_TTL level) | |
| Operating Voltage | 3.7V～5.5V |
| Preheat time | ≤3 minutes |
| Response time | ≤60 seconds |
| Recovery Time | ≤60 seconds |
| Range | 0～5 ppm |
| Resolution | ≤0.01ppm |
| Operating temperature | -20℃～50℃ |
| Working humidity | 15%RH-90%RH (no condensation) |
| Storage temperature | 0～25℃ |
| Service life | 5 years (18℃～25℃ in air) |
