Electrochemical H2 Sensor ME3-H2
Summary:
ME3-H2 electrochemical sensor detect gas concentration by measuring current based on the electrochemical principle, which utilizes the electrochemical oxidation process of target gas on the working electrode inside the electrolytic cell, the current produced in electrochemical reaction of the target gas are in direct proportion with its concentration while following Faraday law, then concentration of the gas could be get by measuring value of current.
Feature:
* Low consumption
* High sensitivity
* Wide linear range
* Good anti-interference ability
* Excellent repeatability and stability
Share To:
APPLICATION
Formaldehyde detector is an instrument for detecting formaldehyde. Generally, semiconductor sensors and electrochemical sensors are used to realize the rapid semi-quantification of formaldehyde in indoor air on the spot, which is characterized by simple structure, small size, intuitive,easy to carry and use.
The combustible gas alarm is an alarm device for detecting gas leakage. The component that reacts to the combustible gas is a gas sensor, and the response signal is converted into an electrical signal through the circuit board. When the combustible gas in the air reaches a certain concentration value, the alarm will alarm. The high-end household combustible gas alarm can automatically start the exhaust equipment and close the gas pipeline valve at the same time. A wireless transmission device can be installed inside the gas alarm to realize overall monitoring and network alarm to ensure the safety of everyone's life and property.
Industrial Combustible Gas Alarm
In the process of industrial use of combustible gas, if the combustible gas is in an incomplete combustion state or has gas leakage, etc., the combustible gas will cause personnel poisoning or fire accidents, directly threatening the life safety of personnel. Therefore, it is necessary to install an industrial-grade gas alarm. If the gas exceeds the standard in the on-site environment, the alarm can give an early warning, thereby reducing the probability of danger.
Didn't Find Your Tarket Application?
Winsen offers tailor-made gas sensor solutions for your industry
PARAMETER
Technical Data Sheet
| Item | Parameter |
| Detection gas | H2 |
| Measurement Range | 0～1000ppm |
| Max detecting concentration | 2000ppm |
| Sensitivity | （0.010±0.005） µA/ppm |
| Resolution ratio | 2ppm |
| Response time（T90） | ≤90S |
| Bias voltage | 0mV |
| Load resistance （recommend） | 10Ω |
| Repeatability | ＜2% output value |
| Stability（／month） | ＜2% |
| Output Linearity | linear |
| Zero drift（-20℃ ～40℃ ） | ≤20ppm |
