Flat Semiconductor Combustible Gas Sensor MP-2
Summary:
MP-2 model with advanced planar construction is comprised of heater and metal oxide semiconductor material of subminiature Al2O3 ceramic plate, fetch out electrode down-lead, encapsulation in metal base and cap. When the target gas exists , the sensor's conductivity is more higher along with the gas concentration rising. Please use simple electrocircuit, convert change of conductivity to correspond output signal of gas concentration.
Feature:
* Good sensitivity to LPG, smoke in wide range
* Small size
* Long lifespan
* Low cost
* Simple circuit
Share To:
APPLICATION
The combustible gas alarm is an alarm device for detecting gas leakage. The component that reacts to the combustible gas is a gas sensor, and the response signal is converted into an electrical signal through the circuit board. When the combustible gas in the air reaches a certain concentration value, the alarm will alarm. The high-end household combustible gas alarm can automatically start the exhaust equipment and close the gas pipeline valve at the same time. A wireless transmission device can be installed inside the gas alarm to realize overall monitoring and network alarm to ensure the safety of everyone's life and property.
Formaldehyde detector is an instrument for detecting formaldehyde. Generally, semiconductor sensors and electrochemical sensors are used to realize the rapid semi-quantification of formaldehyde in indoor air on the spot, which is characterized by simple structure, small size, intuitive,easy to carry and use.
Didn't Find Your Tarket Application?
Winsen offers tailor-made gas sensor solutions for your industry
PARAMETER
Technical Data Sheet
| Model | MP-2 | ||
| Sensor Type | Flat Surfaced Semiconductor | ||
| Standard Encapsulation | Metal Cap | ||
| Target Gas | C3H8, smoke | ||
| Detection range | 200~10000ppm C3H8 | ||
| Standard Circuit Conditions | Loop Voltage | VC | ≤10V DC |
| Heater Voltage | VH | 5V±0.1V AC or DC | |
| Load Resistance | RL | Adjustable | |
| Sensor character under standard test conditions | Heater Resistance | RH | 105Ω±10Ω (room temp.) |
| Heater consumption | PH | ≤240mW | |
| Sensitivity | S | Ro(in air)/Rs( in 2000ppm C3H8)≥3 | |
| Output voltage | Vs | 2.5V~4.0V (in 2000ppm C3H8) | |
| Concentration Slope | α | ≤0.6(R3000ppm/R500ppm C3H8) | |
| Environment Conditions | Operation Temp. | Tao | -10℃~50℃ |
| Storage Temp. | Tas | -20℃~70℃ | |
| Relative Humidity | RH | Less than 95%RH | |
| O2 concentration | O2 | 21%±1%(can't less than 18%) O2 concentration effects sensor's performance. | |
| Preheat time | Not less than 48 hours | ||
| Lifespan | 10 years | ||
