Temperature and Humidity Sensor Module ZS21

Summary:

ZS21 is a brand new product equipped with a dedicated ASIC sensor chip, a high-performance semiconductor silicon-based capacitive humidity sensor and a standard on-chip temperature sensor, and is connected with a high-performance 8-bit microcontroller to output standard I2C data signals. At the same time, each sensor is calibrated in a high-precision temperature and humidity verification box, so the product has good consistency; ZS21 products use special humidity-sensitive materials, so that their performance is extremely stable in high-temperature and high-humidity environments. It has the advantages of fast response, strong anti-interference ability, and high cost performance.

Application
Home appliance fields: home appliance, humidity control, HVAC, dehumidifiers, smart thermostats, and room monitors ;Industrial fields: automobiles, testing equipment, and automatic control devices;
Other fields: data loggers, weather stations, medical and other related temperature and humidity detection devices.

Feature:

* Fully calibrated
* Wide power supply voltage range, from 2.0V to 5.5V
* Digital output, standard I²C signal
* Quick response and strong anti-interference ability
* Excellent long-term stability under high humidity condition
* Low power consumption and high precision

INQUIRY

MANUAL

Share To:

APPLICATION

HVAC

MORE +

Indoor Air Quality Monitoring

The World Health Organization's "Indoor Air Pollution and Health" pointed out that the current level of indoor air pollution is 5-10 times higher than outdoor pollution, and 4% of global diseases are related to indoor air quality, and about 2 million people die prematurely each year from diseases caused by indoor air pollution.

MORE +

Didn't Find Your Tarket Application?
Winsen offers tailor-made gas sensor solutions for your industry

PARAMETER

Specification Product Size

Table 1

Parameter	Condition	Min	Typical	Max	Unit
Resolution	Typical	-	0.024	-	%RH
Accuracy error1	Typical	-	±3	Refer toFigure 1	%RH
Repeatable	-	-	±0.1	-	%RH
Hysteresis	-	-	±1.0	-	%RH
Non-linear	-	-	<0.1	-	%RH
Response time2	τ63 %	-	<8	-	s
Scope of work3	-	0	-	100	%RH
Prolonged Drift4	Normal	-	< 1	-	%RH/yr

Table 2

Parameter	Condition	Min	Typical	Max	Unit
Resolution	Typical	-	0.01	-	°C
Accuracy error5	Typical	-	±0.5	-	°C
Accuracy error5	Max	See figure2			-
Repeatable	-	-	±0.1	-	°C
Hysteresis	-	-	±0.1	-	°C
Response time6	τ63%	5	-	30	s
Scope of work	-	-40	-	85	°C
Prolonged Drift	-	-	<0.04	-	°C/yr
